IPG20N10S4L22AATMA1

Manufacturer Part	IPG20N10S4L22AATMA1
Manufacturer	Infineon Technologies
Description	MOSFET 2N-CH 100V 20A TDSON-8
Category	Discrete Semiconductor Products
RoHS	Lead free / RoHS Compliant
Warranty	365 days
Datasheet	-

Type	Description
Product Status:	Active
FET Type:	2 N-Channel (Dual)
FET Feature:	Logic Level Gate
Drain to Source Voltage (Vdss):	100V
Current - Continuous Drain (Id) @ 25°C:	20A
Rds On (Max) @ Id, Vgs:	22mOhm @ 17A, 10V
Vgs(th) (Max) @ Id:	2.1V @ 25µA
Gate Charge (Qg) (Max) @ Vgs:	27nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds:	1755pF @ 25V
Power - Max:	60W
Operating Temperature:	-55°C ~ 175°C (TJ)
Mounting Type:	Surface Mount, Wettable Flank
Package / Case:	8-PowerVDFN
Supplier Device Package:	PG-TDSON-8-10
