B82722A2302N001
| Manufacturer Part | B82722A2302N001 |
|---|---|
| Manufacturer | EPCOS - TDK Electronics |
| Description | CMC 1.2MH 3A 2LN TH |
| Category | Filters |
| RoHS | Lead free / RoHS Compliant |
| Warranty | 365 days |
| Datasheet | - |
Product Attributes
| Type | Description |
|---|---|
| Product Status: | Active |
| Filter Type: | Power Line |
| Number of Lines: | 2 |
| Impedance @ Frequency: | - |
| Inductance @ Frequency: | 1.2 mH @ 10 kHz |
| Current Rating (Max): | 3A |
| DC Resistance (DCR) (Max): | 56mOhm (Typ) |
| Voltage Rating - DC: | - |
| Voltage Rating - AC: | 250V |
| Operating Temperature: | -40°C ~ 125°C |
| Ratings: | - |
| Approval Agency: | ENEC, UR, VDE |
| Features: | - |
| Mounting Type: | Through Hole |
| Size / Dimension: | 0.894" L x 0.878" W (22.70mm x 22.30mm) |
| Height (Max): | 0.524" (13.30mm) |
| Package / Case: | Horizontal, 4 PC Pin |
