SG5701TZ
| Manufacturer Part | SG5701TZ |
|---|---|
| Manufacturer | Fairchild Semiconductor |
| Description | 75KHZ BICMOS, PDSO6 |
| Category | Integrated Circuits (ICs) |
| RoHS | Lead free / RoHS Compliant |
| Warranty | 365 days |
| Datasheet | - |
Product Attributes
| Type | Description |
|---|---|
| Product Status: | Active |
| Output Type: | Transistor Driver |
| Function: | Step-Up, Step-Down |
| Output Configuration: | Positive |
| Topology: | Flyback |
| Number of Outputs: | 1 |
| Output Phases: | 1 |
| Voltage - Supply (Vcc/Vdd): | 22V |
| Frequency - Switching: | 70kHz |
| Duty Cycle (Max): | 75% |
| Synchronous Rectifier: | No |
| Clock Sync: | Yes |
| Serial Interfaces: | - |
| Control Features: | Current Limit, Frequency Control |
| Operating Temperature: | -40°C ~ 105°C |
| Mounting Type: | Surface Mount |
| Package / Case: | SOT-23-6 |
| Supplier Device Package: | SOT-23-6 |
