PC400J00000F

Type	Description
Product Status:	Active
Number of Channels:	1
Inputs - Side 1/Side 2:	1/0
Voltage - Isolation:	3750Vrms
Common Mode Transient Immunity (Min):	-
Input Type:	DC
Output Type:	Open Collector
Current - Output / Channel:	50 mA
Data Rate:	-
Propagation Delay tpLH / tpHL (Max):	6µs, 3µs
Rise / Fall Time (Typ):	100ns, 50ns
Voltage - Forward (Vf) (Typ):	1.1V
Current - DC Forward (If) (Max):	50mA
Voltage - Supply:	3V ~ 15V
Operating Temperature:	-25°C ~ 85°C
Mounting Type:	Surface Mount
Package / Case:	6-SOIC (0.173", 4.40mm Width), 5 Leads
Supplier Device Package:	5-MFP
